Applications:
• Stage
• Studio
• Installations
Cable Colour:
• Black
|
TECHNICAL DATA: |
|
|
Rated Line Pull |
4500LB(2041kg) single-line |
|
Motor |
3.5hp/2.6kw 12V, Permanent Magnet Motor |
|
Gear Train |
2-stage planetary |
|
Gear Reduction Ratio |
271:1 |
|
Clutch |
rotate 105° |
|
Cable |
φ5.0mm×13m |
|
Drum Size |
φ38mm×74mm |
|
Overall Dimensions |
(L×W×H) 13.8''x4.5''x4.7''(350×114×120mm) |
|
Gross Weight |
25lbs(11kg) |
|
Duty Cycle |
Intermittently |
|
Fairlead |
4-way roller fairlead |
|
Package |
1pc/box,(420×320×150mm) |
|
Mounting Bolt Pattern |
165x76.2mm |
|
Remote Control |
Included |
|
Line Pull |
Lbs |
NO |
1000 |
2000 |
3000 |
4500 |
|
Kgs |
LOAD |
454 |
907 |
1361 |
2041 |
|
|
Line speed |
Ft/min |
14.4 |
9.8 |
8.2 |
6.9 |
4.6 |
|
M/min |
4.4 |
3.0 |
2.5 |
2.1 |
1.4 |
|
|
Motor Current |
amps |
35 |
92 |
120 |
160 |
220 |
|
Layer of cable |
|
1 |
2 |
3 |
4 |
|
|
Rated lin |
Lbs |
4500 |
3840 |
3309 |
2907 |
|
|
Pull per layer |
Kgs |
2041 |
1742 |
1501 |
1319 |
|
|
Cumulative |
Ft |
12.1 |
21.9 |
42.0 |
49.2 |
|
|
Cable capacity |
m |
3.7 |
6.7 |
12.8 |
15 |
|
Mounting Bolt Pattern:
Dimensions
