Applications:
.Stage
.Studio
.Installations
Cable Colour:
.Black
|
TECHNICAL DATA: |
|
|
Rated Line Pull |
15000LB(6804kg) single-line |
|
Motor |
7.0hp/5.1kw 12V, Series Wound motor |
|
Gear Train |
3-stage planetary |
|
Gear Reduction Ratio |
364:1 |
|
Clutch |
turning 180° |
|
Cable |
φ11mm×26m |
|
Drum Size |
φ89mm×224mm |
|
Overall Dimensions |
(L×W×H)23.1”×8.5”×10.1”(588x215x256mm) |
|
Gross Weight |
116.4lbs(52.8kg) |
|
Duty Cycle |
Intermittently |
|
Fairlead |
4-way roller fairlead |
|
Package |
1pc/box,660×270×420mm |
|
Mounting Bolt Pattern |
254 x 114.3mm |
|
Remote Control |
Included |
|
Line Pull |
Lbs |
NO |
4000 |
6000 |
8000 |
10000 |
12000 |
15000 |
|
Kgs |
LOAD |
1814 |
2721 |
3630 |
4536 |
5443 |
6804 |
|
|
Line speed |
Ft/min |
27.9 |
21.0 |
16.7 |
14.8 |
11.2 |
7.5 |
5.6 |
|
M/min |
8.5 |
6.4 |
5.1 |
4.5 |
3.4 |
2.3 |
1.7 |
|
|
Motor Current |
Amps |
70 |
200 |
240 |
291 |
335 |
350 |
392 |
|
Layer of cable |
|
1 |
2 |
3 |
4 |
|
Rated lin |
Lbs |
15000 |
13800 |
11300 |
9358 |
|
Pull per layer |
Kgs |
6804 |
6260 |
5126 |
4245 |
|
Cumulative |
Ft |
14 |
39 |
63 |
85 |
|
Cable capacity |
M |
4.2 |
11.8 |
19.2 |
26.0 |
Mounting Bolt Pattern:
Dimensions
