Applications:
• Stage
• Studio
• Installations
Cable Colour:
• Black
|
TECHNICAL DATA: |
|
|
Rated Line Pull |
3500LB(1587kg) single-line |
|
Motor |
3.3hp/2.5kw 12V, Permanent Magnet Motor |
|
Gear Train |
2-stage planetary |
|
Gear Reduction Ratio |
271:1 |
|
Clutch |
rotate 105° |
|
Cable |
φ4.8mm×13m |
|
Drum Size |
φ38mm×74mm |
|
Overall Dimensions |
(L×W×H)12.6''x4.5''x4.7''(320×114×120mm) |
|
Gross Weight |
26lbs(12kg) |
|
Duty Cycle |
Intermittently |
|
Fairlead |
4-way roller fairlead |
|
Package |
1pc/box,(420×320×150mm) |
|
Mounting Bolt Pattern |
124x76.2mm |
|
Remote Control |
Included |
|
Line Pull |
Lbs |
NO |
1000 |
2500 |
3500 |
|
|
Kgs |
LOAD |
454 |
1134 |
1587 |
|
|
|
Line speed |
Ft/min |
14.4 |
9.8 |
7.2 |
5.9 |
|
|
M/min |
4.4 |
3.0 |
2.2 |
1.8 |
|
|
|
Motor Current |
amps |
35 |
92 |
150 |
180 |
|
|
Layer of cable |
|
1 |
2 |
3 |
4 |
|
|
Rated lin |
Lbs |
3500 |
2934 |
2524 |
2215 |
|
|
Pull per layer |
Kgs |
1587 |
1331 |
1145 |
1005 |
|
|
Cumulative |
Ft |
8.5 |
18.7 |
29.9 |
43 |
|
|
Cable capacity |
m |
2.6 |
5.7 |
9.1 |
13 |
|
Mounting Bolt Pattern:
Dimensions
